Model : chc9212db-ta

Q'ty :

Add To Inquiry

FRAME PLASTIC PBT 94V0
IMPELLER PLASTIC PBT 94V0
LEAD WIRE AWG24 "+" RED "-" BLACK
STANDARD UL 1007
OPTION SIGNAL OUTPUT
BEARING BALL BEARING OR SLEEVE BEARING

Model CHC9212A CHC9212B CHC9212C CHC9212D CHC9212E
Rated Voltage (DCV) 12 12 12 12 12
Operating Voltage (DCV) 6-13.8 6-13.8 6-13.8 6-13.8 6-13.8
Rated Input (W) 1.44 2.40 4.20 6.00 7.20
Rated Current (A) 0.12 0.20 0.35 0.50 0.60
Operating Temperature (ºC) -10~70 -10~70 -10~70 -10~70 -10~70
Storage Temperature (ºC) -40~70 -40~70 -40~70 -40~70 -40~70
Speed (RPM) 2000 2500 3000 3500 4000
Max, .Air Flow M/MIN (CFM) 1.140(40.24) 1.424(50.27) 1.709(60.33) 1.994(70.39) 2.279(80.48)
Max, .Air Pressure mm H2o 5.26 6.575 7.89 9.205 10.52
Noise (DB) 23.5 29.5 35.5 41.5  47.5
Bearing Type ○ ● ○ ● ○ ● ○ ● ○ ●
Weight (g) APPROX.182 APPROX.182 APPROX.182 APPROX.182 APPROX.182
○:Sleeve bearing
●: Ball bering
