Model : CHF9212□□□

Q'ty :

Add To Inquiry

FRAME PLASTIC PBT 94V0
IMPELLER PLASTIC PBT 94V0
LEAD WIRE AWG24 "+" RED "-" BLACK
STANDARD UL 1007
OPTION SIGNAL OUTPUT
BEARING BALL BEARING OR SLEEVE BEARING

Model CHF9212I CHF9212H CHF9212G CHF9212F CHF9212E CHF9212D CHF9212C CHF9212B CHF9212A
Rated Voltage (DCV) 12 12 12 12 12 12 12 12 12
Operating Voltage (DCV) 7-13.2 7-13.2 7-13.2 7-13.2 7-13.2 7-13.2 7-13.2 7-13.2 7-13.2
Rated Input (W) 12.0 10.2 8.4 5.4 3.36 2.16 2.52 1.92 1.32
Rated Current (A) 1.0 0.85 0.70 0.57 0.45 0.28 0.21 0.16 0.11
Operating Temperature (ºC) -10~70 -10~70 -10~70 -10~70 -10~70 -10~70 -10~70 -10~70 -10~70
Storage Temperature (ºC) -40~70 -40~70 -40~70 -40~70 -40~70 -40~70 -40~70 -40~70 -40~70
Speed (RPM) 4800 4500 4100 3800 3200 2900 2600 2300 2000
Max, .Air Flow M3/MIN (CFM) 2.236(78.94) 2.096(74.00) 1.909(67.43) 1.769(62.50) 1.490(52.68) 1.350(47.70) 1.210(42.77) 1.070(37.84) 0.930(32.90)
Max, .Air Pressure mm H2o 12.10 10.64 8.82 7.58 5.38 4.42 3.55 2.78 2.10
Noise (DB) 55.3 51.0 47.5 44.1 41.2 38.0 34.3 31.0 27.0
Bearing Type △ ○ ● △ ○ ● △ ○ ● △ ○ ● △ ○ ● △ ○ ● △ ○ ● △ ○ ● △ ○ ●
Weight (g) APPROX.93 APPROX.93 APPROX.93 APPROX.93 APPROX.93 APPROX.93 APPROX.93 APPROX.93 APPROX.93
OPTION : 12V
△:One ball-One Sleeve
○:Sleeve bearing
●: Ball bering
