30X30X10
- 30×30×10
- 0.061~0.12 M3/MIN
MATERIAL
| FRAME | PLASTIC PBT 94V0 |
|---|---|
| IMPELLER | PLASTIC PBT 94V0 |
| LEAD WIRE |
AWG30 "+" RED "-" BLACK STANDARD UL 1007 |
| OPTION | SIGNAL OUTPUT |
| BEARING | BALL BEARING OR SLEEVE BEARING |
| Model | CHA3005C | CHA3005B | CHA3005A |
|---|---|---|---|
| Rated Voltage (DCV) | 5 | 5 | 5 |
| Operating Voltage (DCV) | 3.0~6.5 | 3.0~6.5 | 3.0~6.5 |
| Rated Input (W) | 0.7 | 0.50 | 0.30 |
| Rated Current (A) | 0.14 | 0.10 | 0.06 |
| Operating Temperature (ºC) | -10~70 | -10~70 | -10~70 |
| Storage Temperature (ºC) | -40~70 | -40~70 | -40~70 |
| Speed (RPM) | 9000 | 7000 | 5000 |
| Max, .Air Flow M3 /MIN (CFM) | 0.12(4.22) | 0.09(3.17) | 0.06(2.15) |
| Max, .Air Pressure mm H2O | 3.37 | 2.64 | 1.85 |
| Noise (DB) | 28 | 21 | 15 |
| Bearing Type | ○ ● | ○ ● | ○ ● |
| Weight (g) | APPROX.8 | APPROX.8 | APPROX.8 |
OPTION : 5V OR 12V
○:Sleeve bearing
●: Ball bering
●: Ball bering
