70X70X20
0.513~1.437 M3/MIN
Model :
chb7012es-o
| FRAME | PLASTIC PBT 94V0 |
|---|---|
| IMPELLER | PLASTIC PBT 94V0 |
| LEAD WIRE |
AWG26 "+" RED "-" BLACK STANDARD UL 1007 |
| OPTION | SIGNAL OUTPUT |
| BEARING |
BALL BEARING OR SLEEVE BEARING |
| Model | CHB7012H | CHB7012G | CHB7012F | CHB7012E | CHB7012D | CHB7012C | CHB7012B | CHB7012A |
|---|---|---|---|---|---|---|---|---|
| Rated Voltage (DCV) | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Operating Voltage (DCV) | 7-13.2 | 7-13.2 | 7-13.2 | 7-13.2 | 7-13.2 | 7-13.2 | 7-13.2 | 7-13.2 |
| Rated Input (W) | 15.35 | 11.19 | 8.88 | 5.65 | 3.60 | 2.16 | 1.80 | 1.20 |
| Rated Current (A) | 0.70 | 0.50 | 0.35 | 0.28 | 0.20 | 0.14 | 0.10 | 0.08 |
| Operating Temperature (ºC) | -10~70 | -10~70 | -10~70 | -10~70 | -10~70 | -10~70 | -10~70 | -10~70 |
| Storage Temperature (ºC) | -40~70 | -40~70 | -40~70 | -40~70 | -40~70 | -40~70 | -40~70 | -40~70 |
| Speed (RPM) | 6000 | 5400 | 5000 | 4300 | 3700 | 3000 | 2500 | 2100 |
| Max, .Air Flow M3 /MIN (CFM) | 1.437(50.69) | 1293(45.62) | 1.197(42.24) | 1.029(36.33) | 0.930(32.84) | 0.733(25.89) | 0.598(21.12) | 0.513(18.13) |
| Max, .Air Pressure mm H2o | 12.46 | 10.09 | 8.65 | 6.40 | 5.15 | 3.47 | 2.35 | 1.74 |
| Noise (DB) | 49.3 | 47.0 | 45.3 | 42 | 36.8 | 29 | 24.7 | 22.7 |
| Bearing Type | △ ○ ● | △ ○ ● | △ ○ ● | △ ○ ● | △ ○ ● | △ ○ ● | △ ○ ● | △ ○ ● |
| Weight (g) | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 | APPROX.55.8 |
OPTION : 12V
△:One ball-One Sleeve
○:Sleeve bearing
●: Ball bering
○:Sleeve bearing
●: Ball bering
